Cab overview, use, operation 1.16 Low-speed control (option) Notice on the low-speed control function The drive speed can be set continuously with the low-speed control. This function is especially useful for operation of hydraulically driven attachments (e.g. rotary broom, rotary hoe) in order to ensure continuous drive speed. Drive speed is set manually via potentiometer 97 at constant engine speed.
Notice ! Continuous setting of the drive speed with potentiometer 97 is only possible in the 1st drive range “turtle” ! • – see Selecting the drive speed on page 1-23
Selecting the drive speed ☞ Select the drive speed as follows:
97
• Press switch 114 to position A ➥ Potentiometer 97 is enabled • Set the drive speed with potentiometer 97 ➥ Drive speed 0 – 7 kph
Notice !
114
Important! Once the low-speed control is no longer needed, turn potentiometer 97 to “Hare” so you can reach maximum speed again in normal operation!
A B Fig. 17: Low-speed control
Serv-HB 40702 – Edition 2.0 * 407-02s0310_a4_Übersicht-Bedienung.fm
1-23
