Cab overview, use, operation Synchronising a machine with front axle and diagonal steering (option) D
Notice!
V
Steering synchronisation is only possible in the “4 wheel” steering mode! A
☞ Proceed as indicated in the Operator’s Manual • Pull lock S on lever 48 out of the detent • Move lever 48 to 4 wheel steering mode (A) and release lock S
S
48
Notice! Lock S is spring-loaded and locks into place automatically as soon as a steering mode has been selected.
Fig. 16: Steering synchronisation
• Select a drive range • Select the driving direction with the switch on the control lever • At low drive speed, turn the steering wheel to the left or right as far as it will go and try turning it even further in the end position against the pressure for a few seconds • Turn the steering wheel rapidly back to straight-ahead position • Select the steering mode and perform a test run to check that the wheels on the front and rear axles run in the same track
Notice! Contact your dealer if this does not synchronise the wheels.
1-22
Serv-HB 40702 – Edition 2.0 * 407-02s0310_a4_Übersicht-Bedienung.fm
