Page 27

Cab overview, use, operation .

1.10 Avoiding running the engine under low-load conditions Caution! The running performance of the engine can be negatively affected if it runs at idling speed or high speed and at less than 20 % of the load. ☞ Effects: • Operating temperature is not reached • Increased lube oil consumption • Lube oil in exhaust system, and therefore diesel engine contamination • Blue smoke in exhaust ☞ We recommend running the diesel engine at loads of over 20 % during regular operation

1.11 Stopping the diesel engine

0

1

Caution!

2

In order to avoid heat accumulation and damage to the exhaust gas turbocharger, do not stop the diesel engine from full throttle! ☞ Let the diesel engine run at idling speed for about 2 minutes and then switch it off

3

64 Fig. 12: Stop the diesel engine

☞ Proceed as follows: • Apply the parking brake to the last notch • Turn the ignition key (preheating start switch) to position “0” and remove the ignition key

Serv-HB 40702 – Edition 2.0 * 407-02s0310_a4_Übersicht-Bedienung.fm

1-17
