Cab overview, use, operation Variable displacement motor number Seen on lower side of machine. The type label (arrow) is located on the variable displacement motor housing (flanged on the transfer gearbox).
Fig. 7:
Variable displacement motor type label
Gearbox number Seen on lower side of machine. The type label (arrow) is located on the gearbox housing, flanged on the front axle
Fig. 8:
Gearbox type label
Front or rear axle number Seen on lower side of machine. The type label is located on the axle support (arrow). ➥ Rear axle (on the left in driving direction) ➥ Front axle (on the right in driving direction)
Fig. 9:
1-10
Rear axle and gearbox type label
