Cab overview, use, operation 1.6 Type labels and component numbers Explanation of “Book” symbol The “Book” symbol on the signs and type labels indicates that the Operator’s Manual contains more detailed information and explanations.
Fig. 2:
Explanation of “Book” symbol
Serial number The serial number A is stamped on the machine frame (next to the mudguard attachment, at the front right). It is also located on the type label B. The CE mark C on the type label means that the machine meets the requirements of the Machine Directive (2006/42 EC) and that the conformity procedure has been performed.
A
Type label indications (example) B
C B
1 2 3 4 5 Fig. 3:
6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
Machine model Version Serial no. Year of construction Output (kW) Front gross axle weight rating (kg) Rear gross axle weight rating (kg) Gross weight rating (kg) Dead weight (kg) Maximum payload (kg)
407 407-02 407 02 00032 2010 50 4480 4480 7500 – –
Other data: – see chapter 6 “Technische Daten” on page 6-1
Type label location
Cab number The type label (arrow) is located in the cab, on the top right frame member.
Fig. 4:
1-8
Cab type label
