Maintenance Mode

Cha pte r C

C-1 Operation Keys and Menu 1.1 Operation keys

Fig. 1.1.1

Cha pte r C

Liquid crystal display (LCD)

AML display control panel

Operation keys

The following keys are used in the maintenance and adjustment mode. On and after, < > in the descriptions indicates the operation key.

Key No.

Key name

Function

1

<

Function 1>:

Used for functions displayed on the adjustment mode screen with F1.

2

<

Function 2>:

Used for functions displayed on the adjustment mode screen with F2.

3

<

Function 3>:

Used for functions displayed on the adjustment mode screen with F3.

4

<

Function 4>:

Used for functions displayed on the adjustment mode screen with F4.

10

<

Cancel>:

Used to quit the menu that is running.

11

<

Display change>:

Used to change the displayed information.

12

<

Set>:

Used to determine the menu selection or to register the adjustment value.

13

<

Check>:

Used to erase the adjustment value for the precision adjustment.
