User Mode
Cha pte r B
Cha pte r B
6.1.7 Load radius limit stop Restriction is implemented to the operations exceeding the load radius that is set with the area limit. Code at stop: W0029 Cancel: 100% stop cancel (Di6: ON) Stop operation: (×: Stop operation) Main winch
Aux. winch
Boom telescoping
Boom elevation
Jib telescoping
Up
Up
Ext.
Rse.
Lwr.
Ext.
×
×
Down
Down
Ret.
×
Jib tilt
Ret.
Rse.
Lwr.
Slewing Right
Left
Jib mounting Ext.
Stw.
×
6.1.8 Elevation lower limit As for the cranes whose moment detection is the differential pressure detection type, the moment detection becomes no longer possible when the elevating stroke end is reached. This function stops the elevation before the lowering stroke end is reached. However, to achieve the traveling configuration, when the slewing angle and boom length condition are satisfied, the lowering can be performed to the stroke end without a stop. Stop condition: Boom angle ≤ Boom lowering stop angle A°, and in the crane status other than the one specified . Cancel: 100% stop cancel Code at stop: W0054 Stop operation: (×: Stop operation) Main winch
Aux. winch
Up
Up
Down
Down
Boom telescoping Ext. Ret.
Boom elevation Rse. Lwr.
Jib telescoping Ext. Ret.
Jib tilt Rse.
×
B - 45
W301-0471E
Lwr.
Slewing Right
Left
Jib mounting Ext. Stw.
