4.5.9 Setting of anemometer alarm threshold value (Option) While the anemometer is used, if the detected wind speed exceeds the threshold value, an alarm sounds. Follow the procedure below to register the threshold value. When the wind speed measured by the anemometer exceeds the registered threshold value, an alarm sounds, and the error code "W0097" is shown on the AML. 1. Select the anemometer alarm threshold value setting menu icon, and press the <
> key (set).
• The pop-up window for wind speed alarm threshold value setting is shown on the display panel.
2. Press the < > key (-) or < > key (+) to adjust the threshold value. Press the < > key (+) to increase the threshold value and the < > key (-) to decrease it. You can set the threshold value between 0.0 m/s and 14.0 m/ s.
3. Press the <
> key (set).
• When registration is completed, the pop-up window closes and the AML returns to the crane operation state. To abort the registration, press the <
> key
(cancel). The pop-up window closes and the AML returns to the crane operation status before registration. Even after the AML is turned off, the registered information is retained. When the AML is turned on, the operation starts with the retained registered information.
