4.5.5 Fuel consumption history display The fuel consumption history is displayed. 1. Hoist down a load to the ground and set each control lever and pedal to the neutral position.. 2. Select the fuel consumption history icon, and then press the <
> key (set).
•The screen for fuel consumption history appears.
3. The display changes when the <
> key (display
change) is pressed. •The fuel consumption history is shown in either a barograph or number. •The items shown on the numeric display screen are as follows. L(N) ....... Fuel consumption during standby (liter) L(D) ....... Fuel consumption during crane operation (liter) min/L....... Fuel consumption ratio during crane operation (minute/liter). You can change the unit of fuel consumption ratio in min/L (minute/ liter) or L/h (liter/hour) by pressing F2 (unit change) key.
The measurements restart when < > key (reset) is pressed. The previous records are moved down by pressing < > key (reset). 6 previous records including the current rate are displayed. You can reset the histories both for traveling and crane operation at the same time by pressing < > key (reset) and hold it for a while. Press < > key (cancel) to exit the history display. The pop-up window closes and the AML returns to the crane operation state. L(N) and L(D) include the fuel consumption during on-rubber creep operation.
B - 33
