User Mode
Cha pte r B 4.5.3 Eco mode selection
Select a crane operation mode when Eco mode switch is "ON". ・Eco mode 1 : In this mode, the crane restricts the maximum engine speed, consumes less fuel and makes less noise compared with when ECO mode is "OFF". ・Eco mode 2 : In this mode, the crane consumes further less fuel and makes further less noise compared with when ECO mode 1 is selected. A crane operation becomes slower by restricting the maximum engine speed. Select a suitable ECO mode depending on crane operation.
1. Select the Eco mode selection icon, and then press the <
> key (set).
•The pop-up window for Eco mode selection appears on the display panel. 2. Press the < > key (backward) or < > key (forward) to select one of the Eco mode icons. •The selected icon is highlighted. 3. Press the <
> key (set).
•After the registration is completed, the pop-up window closes and the AML returns to the crane operation state. •When the ECO mode switch is turned "ON", the ECO mode indicator (ECO mode 1 or ECO mode 2) is displayed.
To cancel the selection, press the <
> key
(cancel). The pop-up window closes and the AML returns to the crane operation state without changing registration. Even after the AML is turned off, the registered information is retained. When the AML is turned on, the operation starts with the retained information.
B - 31
W301-0471E
