User Mode
Cha pte r B
Cha pte r B
B-4 Other Functions There are other 6 functions as shown below. No. 1 2 3 4 5 5-1 5-2 5-3 5-4 5-5 5-6 5-7 6
GR-300EX-3
GR-500EX-3 GR-600EX-3 GR-800EX-3
○ ○ ○ ○
○ ○ ○ ○
○ ○ ○ -○ ○ ○ ○
○ ○ ○ ○ ○ ○ ○ ○
Work range limit function TARE function Fuel consumption display function Mute alarm function Preset menu – Eco mode selection – Activating/deactivating winch drum rotation buzzer – Fuel consumption history display – Selection of winch to be used – Adjustment of display panel contrast – Transmission of telematics data – Setting of anemometer alarm threshold value (Option) Back light On (Off) Function
Each function is as follows:
4.1 Work range limit function NOTICE If the work range limit is registered too close to an obstacle, the machine can hit the obstacle depending on the crane configuration and operation methods. Consider a sufficient allowance when you register the limit.
The work range limit function restricts the operation of the crane to the pre-registered boom angle (upper limit, lower limit), lifting height, load radius, and slewing angle (left, right). Use this function when operating the machine in a place where there are obstacles around the machine or when requiring the work range limit of the boom. When the crane reaches the registered work range, the limit function works as shown below: Work range limit function Boom angle upper limit Boom angle lower limit Lifting height limit Load radius limit Left slewing limit Right slewing limit
Crane state • Crane stops automatically. • AML built-in buzzer
B - 21
W301-0471E
