Components of AML System
Cha pte r A CN5 connector Pin No.
Cha pte r A
Signal names and functions
Name
- Signal name: External indicator lamp (90% to 100%, yellow) When the moment load factor is 90% or more and less than 100%, the yellow external indicator lamp lights. Output condition: (1), (2) and (3) (1): Moment load ratio is 90% or more and 100% or less. (2) 100% stop cancel indication (Di6) is "Not canceled" status. (3): Anti-two-block cancel indication (Di5) is "Not canceled" status.
15
Do15-
When in the boom operation with jib elected (during main operation with jib elected), the yellow external indicator lamp lights when the moment load ratio described below is reached. Output
Outrigger extension width
GR-300EX-3
GR-500EX-3
GR-600EX-3
GR-800EX-3
Maximum extension
84% or more Less than 94%
82% or more Less than 92%
78% or more Less than 88%
84% or more Less than 94%
Middle extension 2
83% or more Less than 93%
81% or more Less than 91%
77% or more Less than 87%
83% or more Less than 93%
Middle extension 1
81% or more Less than 91%
78% or more Less than 88%
70% or more Less than 80%
82% or more Less than 92%
Output when condition is met: OFF output - Signal name: External indicator lamp (100% or more, red) When the moment load ratio is 100% or more, the red external indicator lamp lights. Output condition: (1) or (2) or (3) (1): Load factor exceeds 100%. (2) 100% stop cancel indication (Di6) is "Canceled" status. (3): Anti-two-block cancel indication (Di5) is "Canceled" status.
16
Do16-
When in the boom operation with jib elected (during main operation with jib elected), the red external indicator lamp lights when the moment load ratio described below is reached. Output
Outrigger extension width
GR-300EX-3
GR-500EX-3
GR-600EX-3
GR-800EX-3
Maximum extension
94% or more
92% or more
88% or more
94% or more
Middle extension 2
93% or more
91%or more
87% or more
93% or more
Middle extension 1
91% or more
88% or more
80% or more
92% or more
Output when condition is met: OFF output
A - 22
W301-0471E
