Cha pte r D
Adjustment mode
Cha pte r D
<Operation method> The currrent setup stae is enclosed by a frame. Press the < > key (scroll up) or the < > key (scroll down) key to select the state to set up, and press the < Fig. 6.1.1. Perss the <
> key to register the selected state and go back to the screen of
> key , to go back to the set up performance menu of Fig. 6.1.1 without registartion.
6.1.1 Details of menu items [1] When specification selection flag of winch drum position adjustment value selection is " rear←→front / rear" (0). (A) When the specification selection flag of winch drum selection availability is "1" (available) and selection is performed by pop-up menu for winch drum position selection from the user prset menu (B-4.5). Change of the winch drum position selection adjustment value is possible only by the setting of the user preset menu. (See B-4.5.6) (1) “Winch drum front / rear” The winch drum position is determined only by the boom / jib lift state, and the winch position cannot be selected in the user preset menu. The position for boom lift state is fixed in the front position. The position for S/T and jib lift states is fixed in the rear position. (2) “Winch drum rear” The winch drum position is determined by the boom / jib lift state, and the selected content of the winch position select in the user preset menu. The position for boom lift state is fixed in the rear position. The position for S/T and jib lift states is fixed in the position selected in the user preset menu. [2] When specification selection flag of winch drum position adjustment value selection is " front←→front / rear" (1). (A) When the specification selection flag of winch drum selection availability is "1" (available) and selection is performed by pop-up menu for winch drum position selection from the user prset menu (B-4.5). Change of the winch drum position selection adjustment value is possible only by the setting of the user preset menu. (See B-4.5.6) (1) “Winch drum front / rear” The winch drum position is determined only by the boom / jib lift state, and the winch position cannot be selected in the user preset menu. The position for boom lift state is fixed in the front position. The position for S/T and jib lift states is fixed in the rear position. (2) “Winch drum front” The winch drum position is determined by the boom / jib lift state, and the selected content of the winch position select in the user preset menu. The position for boom lift state is fixed in the front position. The position for S/T and jib lift states is fixed in the position selected in the user preset menu.
D - 27
W301-0471E
