Cha pte r D
Adjustment mode
Cha pte r D
2.5.2 Outrigger Length Span Adjustment - Fully extend all four outrigger beams. - Until "RFront O/R" and "Span adjustment value" become highlighted on the LCD (Fig. 2.1.1), press the < > key (backward) or the < > key (forward). RFront O/R [m]
Value
ZERO
SPAN
3.568
1.275
3.600
Detected Right Front outrigger length
Span adjustment value
- Operate the < > key (-) and the < > key (+) so that the detected Right Front outrigger length becomes the span adjustment value. When the adjustment length is reached, press the <
> key to register the
adjustment value. After the adjustment value is registered, " " is shown at the left of span adjustment value.
- Also for the outrigger length of Left Front, Right Rear, and Left Rear, operate the < > key (backward) and the < > key (forward) to show the span point adjustment display, and then perform the adjustment and registration. Display of Left Front outrigger span adjustment Value
ZERO
LFront O/R [m] 3.568
1.275
SPAN
3.600
Display of Right Rear outrigger span adjustment RRear O/R [m]
Value
ZERO
3.568
1.275
SPAN
3.600
Display of Left Rear outrigger span adjustment LRear O/R [m]
Value
ZERO
3.568
1.275
SPAN
3.600
2.5.3 Adjustment Check - Fully retract all four outrigger beams again. - The adjustment is completed when the detected outrigger length is within the standard tolerance. If the value is out of the standard tolerance, perform the zero adjustment and span adjustment again.
D - 14
W301-0471E
