Cha pte r D
Adjustment mode
Cha pte r D
2.5 Outrigger Length Adjustment The outrigger adjustment can be performed with four outriggers at the same time, or separately with each outrigger.
2.5.1 Outrigger Length Zero Adjustment - Fully retract all four outrigger beams. - Until "RFront O/R" and "Zero adjustment value" become highlighted on the LCD (Fig. 2.1.1), press the < > key (backward) or the < > key (forward). RFront O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
Detected Right Front outrigger length
Zero adjustment value
- Operate the < > key (-) and the < > key (+) so that the detected Right Front outrigger length becomes the zero adjustment value. When the adjustment length is reached, press the <
> key to register the
adjustment value. After the adjustment value is registered, " " is shown at the left of zero adjustment value.
- Also for the outrigger length of Left Front, Right Rear, and Left Rear, operate the < > key (backward) and the < > key (forward) to show the zero adjustment display, and then perform the adjustment and registration. Display of Left Front outrigger zero adjustment Value
ZERO
SPAN
LFront O/R [m] 1.281
1.275
3.600
Display of Right Rear outrigger zero adjustment RRear O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
Display of Left Rear outrigger zero adjustment LRear O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
D - 13
W301-0471E
