Cha pte r D
Adjustment mode
Cha pte r D
Table 1.3.1 shows the adjustment main menu list (items differ depending on the model). Table 1.3.1 Adjustment main menu list Displayed menu
Work contents
1. Detector Adjustment
Detector adjustment
2. Moment Adjustment
Moment and load radius adjustment
3. Valve Adjustment
Storing of actuator's operating speed characteristics for valve control output
4. Precision Adjustment
Precision correction (adjustment of displayed load and load radius precision)
5. Length Detector Correction
Adjustment value setting of boom length detection value
6. Option Select
Selection of availability of slewing angle detector, anemometer, main pressure detector, etc.
7. Set up performance
Setting of performance-related data
8. Emergency History Erase
Erasing of AML emergency or override SW history Will not be displayed after erasing for three times.
9. History Erase
Erasing of operation history Will not be displayed after erasing for three times.
10. O/R Emergency History Erase
Erasing of outrigger emergency setting history Will not be displayed after erasing the operation history for three times.
11. Slow Stop Adjustment
Adjustment of slow stop deceleration table
12. Telematics setup
Setting of permission / prohibition
13. Fuel Monitor E/G
Setting of engine model
14. Vehicle System Error Erase
Erase of error history of vehicle system (ECU)
15. Meter Rewrite
Writing of hourmeter value and odometer value stored in DCU2 to CMA
D-7
W301-0471E
When AML board is replaced.
