Adjustment mode
Cha pte r D
1.3.4 Adjustment Main Menu When the ID code is correctly input, the adjustment main menu is displayed as shown in Fig. 1.3.3.
Fig. 1.3.3 Adjustment main menu display Perform the selection of adjustment menu as described below. Pressing the < > key (scroll up) or the < > key (scroll down) moves the selected maintenance menu item (highlighted). After the desired menu is selected, pressing the <
> key starts the selected menu.
Be sure to perform the adjustment in sequence starting from the menu No.1. To terminate the adjustment mode, press the <
> key while the adjustment main menu is being displayed.
Note: When performing adjustments, always set up the crane on the firm level surface and fully extend outriggers (except for outrigger length adjustment).
D-6
W301-0471E
