Maintenance Mode
Cha pte r C
Cha pte r C
2.8.15 VCU check, Ao check Displays the status of VCU Ao. In the VC check selection menu of Fig. 2.8.1, select "Ao Check (VCU)", and press the < display the Ao check (VCU) screen shown in Fig. 2.8.13.
> key (set) to
Pressing the < > key (previous page) or the < > key (next page) changes the pages. To go back to the VCU check selection menu, press the <
> key (cancel).
Fig. 2.8.13 Display screen of VCU Ao check state <Description of display contents> Port Ao 1 to Ao 3: Ao port of VCU Volt: Input terminal voltage - (hyphen) indicates that no signal is received. D/A: Value with which the input voltage is converted to digital value (0 to 5 V is converted to 0 to 1023.) - (hyphen) indicates that no signal is received. FB: Feedback value (A/D value up to 10 digits in a decimal number) - (hyphen) indicates that no signal is received.
C - 27
W301-0471E
