Maintenance Mode
Cha pte r C
Cha pte r C
2.8.14 VCU check, DoPow_Moni check Displays the status of VCU DoPow_Moni. In the VC check selection menu of Fig. 2.8.1, select "DoPow_Moni Check (VCU)", and press the < (set) to display the DoPow_Moni check (VCU) screen shown in Fig. 2.8.12. Pressing the < > key (previous page) or the < > key (next page) changes the pages. To go back to the VCU check selection menu, press the <
> key (cancel).
Fig. 2.8.12 Display screen of VCU DoPow_Moni check state <Description of display contents> Port Pwr 1 to Pwr 18: DoPow_Moni port of VCU Out ON
: Output ON (CAN received data "0")
OFF
: Output OFF (CAN received data "1")
- (hyphen)
: No signal received
C - 26
W301-0471E
> key
