Maintenance Mode
Cha pte r C
Cha pte r C
2.8.13 VCU check, Do check Displays the status of VCU Do. In the VC check selection menu of Fig. 2.8.1, select "Do Check (VCU)", and press the < display the Do check (VCU) screen shown in Fig. 2.8.11. Pressing the < > key (previous page) or the < > key (next page) changes the pages. To go back to the VCU check selection menu, press the <
> key (cancel).
Fig. 2.8.11 Display screen of VCU Do check state <Description of display contents> Port Do 1 to Do 64, M_SOL 1 to M_SOL 2, KEY OFF, ACC ON: Do port of VCU Ao 1 CUT to Ao 3 CUT, SUB OFF, SUB NMI, SUB OE 1 to 18 Out ON
: Output ON (CAN received data "1")
OFF
: Output OFF (CAN received data "0")
- (hyphen)
: No signal received
FB ON
: Output ON (CAN received data "0")
OFF
: Output OFF (CAN received data "1")
- (hyphen)
: No signal received
C - 25
W301-0471E
> key (set) to
