2.8.11 VCU check, Ai check Displays the status of VCU Ai. In the VC check selection menu of Fig. 2.8.1, select "Ai Check (VCU)", and press the < display the Ai check (VCU) screen shown in Fig. 2.8.9.
> key (set) to
Pressing the < > key (previous page) or the < > key (next page) changes the pages. To go back to the VCU check selection menu, press the <
> key (cancel).
Fig. 2.8.9 Display screen of VCU Ai check state
<Description of display contents> No. Item No. Port Ai 1 to Ai 12, PWR, CHG, PWR_DET : Ai port of VCU Volt
: Input terminal voltage. - (hyphen) indicates that no signal is received.
A/D: Value with which the input voltage is converted to digital value (0 to 5 V is converted to 0 to 1023.) - (hyphen) indicates that no signal is received.
