2.8.10 VCU check, Di check Displays the status of VCU Di. In the VC check selection menu of Fig. 2.8.1, select "Di Check (VCU)", and press the < display the Di check (VCU) screen shown in Fig. 2.8.8.
> key (set) to
Pressing the < > key (previous page) or the < > key (next page) changes the pages. To go back to the VCU check selection menu, press the <
> key (cancel).
Fig. 2.8.8 Display screen of VCU Di check state <Description of display contents> Port Di 1 to Di 32, Di_IN_KEY : Di port of VCU Detect Close
: Contact ON (CAN received data "1")
Open
: Contact OF (CAN received data "0")
- (hyphen)
: No signal received
[NOTICE] Types for Di 25 to Di 32 can be switched between 24 V suction and 12 V discharge. Therefore, both (+) and (-) are displayed. (Example) For Di 25, Di 25 (+) and Di 25 (-) are displayed. Di 25(+) Di 25(-)
Note that only one of the two types changes. Check the detection status of both (+) and (-).
