Model 5200 High-Level Orderpicker
Section 6. Messages, Codes, and Tests Operator Display Messages
Battery Indicator Messages
than one code is present (“stacked codes”), there are rapid flashes between codes.
The battery indicator has five LEDs used in three prioritized modes of operation (3 is the highest priority). See Table 6-2. Table 6-2.
Battery Indicator Messages
Status Mode
Priority
Display
3 (highest)
Series of blinks for each digit (all 5 blink together); see “Operator Display Fault Codes” on page 6-41.
Info Display
2
Blinks a single LED to indicate a particular condition; see Table 6-3, “Info Display Messages,” on page 6-3.
Battery State-ofCharge
1 (lowest)
Steady LEDs represent the current state-of-charge.
Fault Code
There is no limit to the number of stacked codes, but only the highest priority codes are displayed. When these codes are resolved, the next highest codes are displayed until they are resolved. Each code is explained later in this section. See “Operator Display Fault Codes” on page 6-41.
Info Display Each LED represents a different condition. See Figure 6-2.
The battery indicator always shows the mode with the highest priority that is active. For example, an Info Display message overrides a Battery State-of-Charge message. 6 6
Fault Codes All five LEDs flash in series to identify the fault code. Each series (code) has two digits. If more
Table 6-3.
Figure 6-2.
Battery Indicator Info Display Messages
Table 6-3 shows the cause and how to clear each display.
Info Display Messages Display
Cause
How To Clear
Top LED blinking
The EPO is depressed.
Pull out the EPO switch and reset the key switch.
2nd LED from top blinking
The Deadman pedal must be depressed before you request motion.
1. Return controls to neutral. (Release throttle) 2. Step on the deadman pedal.
(If optional sidegate with interlocks is attached) 3rd LED from top blinking
The sidegate is up when requesting travel or lift/lower.
Lower the sidegate.
4th LED from top blinking
The carriage reached lift-limit (if equipped).
Press lift-limit bypass switch to continue lifting.
Bottom LED blinking
The battery charge is too low. Lift cutout is initiated.
Install a fully-charged battery.
Publication Number: 1043922B, Revised: 2 Sept 2015
6-3
