Model 5200 High-Level Orderpicker
Section 5. Troubleshooting Electrical Troubleshooting
Setting Battery State-of-Charge Cutout 1. Fill, charge, and install a battery that is typical of the batteries normally used in this application. 2. Have a customer operator use the lift truck in the normal application until cutout occurs. 3. Allow the battery to cool and stabilize for at least two hours. 4. Before filling the battery, either take specific gravity readings or measure open circuit voltage of the battery cells. 5. Compare the measurements with the battery manufacturer’s recommendations for maximum discharge. 6. Adjust the cutout value as needed and repeat the previous steps until battery cutout occurs at the desired discharge level. NOTE: Additional BSOC adjustment is available using FlashWare.
Publication Number: 1043922B, Revised: 2 Sept 2015
5-5
