Section 8. Theory of Operation
Model 5200 High-Level Orderpicker
Pinout Matrix Item #
Connection
Function Description
Signal Source
SignalUser
260
JPC4-2
Not activated = >1.3VDC activated = <1.0VDC
Carriage Manager
Lift/Lower Alarm
261
This is the input from the right tractor sensor coil to the Filter Card.
Centered over the wire you should see around 32mVAC. 1.5 in. to the right you should see around 75mVAC. 1.5 in. left you should see around 15mVAC
Antenna Card
Filter Card
NEAR WIRE
This is the input from the tractor near wire sensor coil to the Filter Card.
Centered over the wire you should see around 70mVAC. 1.5V to either side you should see around 100mVAC
Antenna Card
Filter Card
JPW2-3
LEFT
This is the input from the left tractor sensor coil to the Filter Card.
Centered over the wire you should see around 32mVAC. 1.5 in. to the right you should see around 15mVAC. 1.5 in. left you should see around 75mVAC
Antenna Card
Filter Card
264
JPW2-5
T0
Communication lines used by the Wire Guidance Manager to tell the tractor Antenna Card what frequency it should be looking for.
No useful voltages are measurable
Filter Card
Antenna Card
265
JPW2-6
T1
Communication lines used by the Wire Guidance Manager to tell the tractor Antenna Card what frequency it should be looking for.
No useful voltages are measurable
Filter Card
Antenna Card
266
JPW2-7
T2
Communication lines used by the Wire Guidance Manager to tell the tractor Antenna Card what frequency it should be looking for.
No useful voltages are measurable
Filter Card
Antenna Card
Theory of Operation
Normal Level
L/L Alarm
Path for CM to Supply B- to the Lift/Lower alarm relay.
JPW2-1
RIGHT
262
JPW2-2
263
8-32
