Section 8. Theory of Operation
Model 5200 High-Level Orderpicker
Pinout Matrix Item #
Connection
152
JPT3-1
153
Function Description
Signal Source
Theory of Operation
Normal Level
STEER POSITION A (S8)
Output of Home Sensor Prox. used by the STM to determine if the drive unit is CW or CCW of center. When over metal (CW), the switch is closed and the output is low. When not over metal (CCW), the switch is open and the output is hi.
Over metal= less than 1V Not over metal= 6.5V
Steer Position Prox.
Steer Controller Card
JPT3-3
DGND
DGND is the B– for the Steer Position Prox. switch (S8). It is connected through the STM via B– cable at the TPA.
<0.5VDC wrt TP4 (B–)
Steer Position Prox.
STM
154
JPT2-1
NC
Not connected to any circuitry on the STM.
NA
NA
NA
155
JPT2-3
DGND
The B– for the Guidance Manager. It is connected through the STM.
<0.5VDC wrt TP4 (B–)
STM
Steer Controller Card
156
JPT2-4
BUS+
The wire that carries the positive component of the digital communications between the STM and the Guidance Manager. No usable information can be gained by measuring the voltage on this wire.
No useful voltages are measurable
STM / WGM
STM / WGM
157
JPT2-2
BUS-
The wire that carries the negative component of the digital communications between the STM and the Guidance Manager. No usable information can be gained by measuring the voltage on this wire.
No useful voltages are measurable
STM / WGM
STM / WGM
158
JPC1-11
LED 1
Takes LED 1 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
159
JPC1-10
LED 2
Takes LED 2 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
160
JPC1-9
LED 3
Takes LED 3 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
171
JPC1-8
LED 4
Takes LED 4 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
172
JPC1-7
LED 5
Takes LED 5 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
173
JPC1-6
LED 6
Takes LED 6 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
174
JPC1-5
LED 7
Takes LED 7 to B– when the CM wants it turned ON.
LED Off=13V LED On=16.5V WRT B+
Carriage Manager
Display Card
8-26
SignalUser
