Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Mast Section
Load Wheels
Load Wheels
Use extreme care whenever the lift truck is jacked up. Keep hands and feet clear from the vehicle while jacking the lift truck. After the lift truck is jacked, place solid blocks beneath it to support it. Do not rely on the jack alone to support the lift truck. See “Jacking Safety” on page 2-8. 1. Raise the operator platform approximately 1 ft. (0.3 m) from the floor. Place a 4 x 4 in. (100 x 100 mm) block across the top of the baselegs underneath the platform. 2. Turn the key switch OFF and disconnect the battery. 3. Jack up the baseleg high enough to clear the load wheel from under the baseleg. Place a block under the baseleg. 4. Remove the snap ring from the axle. See Figure 7-219. Snap Ring
Axle
7
Figure 7-219. Load Wheel
5. Drive out the axle. The load wheel falls out of the baseleg. See Figure 7-219. 6. Replace the load wheel assembly. 7. Drive the axle back through the wheel and baseleg. 8. Install a new snap ring. 9. Remove the blocks.
Publication Number: 1043922A, Revised: 2 Sept 2015
7-121
