Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Mast Section
Carriage With Two-Stage Mast
Carriage With Two-Stage Mast 6. Remove the finger guard. See Figure 7-202.
Use extreme care whenever the lift truck is jacked up. Never block the lift truck between the telescopic and the floor. Keep hands and feet clear from the vehicle while jacking the lift truck. After the lift truck is jacked, place solid blocks beneath it to support it. Do not rely on the jack alone to support the lift truck. See “Jacking Safety” on page 2-8.
Removal 1. Turn the key switch OFF and disconnect the battery. 2. Remove the operator console cover. See “Operator Console Cover” on page 7-11.
Finger Guard
7
Figure 7-202. Finger Guard
7. Disconnect the inside chain anchors at the bottom of the carriage. See Figure 7-203.
3. Disconnect JPC8 and JPC9 from the Carriage Manager and cut the cable tie from the tractor side. Inside Chain Anchor
Do not place hands between the masts before blocking the carriage. 4. Feed the cable through the carriage to the tractor. 5. Lift the carriage high enough to create slack on the chains. Block the carriage.
7
Figure 7-203. Inside Chain Anchor, View From Operator Platform
8. Place the disconnected end of the chains over the top of the mast, toward the tractor. See Figure 7-204.
Publication Number: 1043922A, Revised: 2 Sept 2015
7-105
