Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Mast Section
Carriage with Three-Stage Mast
Inspection 1. Remove the operator compartment console cover and tractor cover. 2. Lift the operator platform just high enough to have the chain anchor/pivot rocker visible through the opening under the operator control panel. 3. Place blocking under the operator’s platform. Lower the platform on the support. 4. Turn the key switch OFF and disconnect the battery. Open the emergency lower valve. The center cylinder moves down and the chains go slack. If the center cylinder does not go down far enough to slacken the chains, push down on the top of the cylinder. This allows the chain anchor to be visible for inspection. See Figure 7-192.
With chains slack, inspect the chain anchor here
7
Figure 7-193: After Chain Goes Slack
6. Reconnect the battery connector and turn the key switch ON. Close the emergency lower valve. 7. Lift the platform slowly to take slack out of the chains and to clear the support from beneath it. 8. Remove the support and lower the platform. 9. Reinstall all covers.
7
Figure 7-192: Before Chain Goes Slack
5. Inspect the chain anchor and pivot rocker for wear and replace if necessary. See Figure 7-193.
Publication Number: 1043922A, Revised: 2 Sept 2015
7-101
