Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Electrical Components
Traction Motor
Traction Motor
from the steer motor mounting plate. See Figure 7-127.
Removal 1. Remove the tractor covers. See “Tractor Covers” on page 7-11.
Install screws here.
2. Turn the drive unit using the steering wheel so you can reach the power cables. 3. Turn the key switch OFF and disconnect the battery. 4. Remove the brake from the traction motor (if the motor is to be replaced). See “Brake” on page 7-52. 5. Disconnect the power cables from the traction motor. Note the location for installation and label if necessary.
Flange
Drive Unit
7
Figure 7-127. Breaking Seal Between Motor and Drive Unit
6. Remove the steer motor. See “Steer Moor” on page 7-18. 7. Remove the dipstick and plug. See Figure 7-126.
11. Attach a suitable hoist to the traction motor and lift the motor out of the lift truck.
Installation 1. Clean sealant from the motor flange and cap screws for the traction motor. See Figure 7-128. Dipstick Flange
Pinion Gear 7
Figure 7-126. Removing Dipstick
8. Remove the bracket that activates the home proximity switch. 9. Remove the bolts that secure the traction motor to the drive unit. 10. Break the seal between the traction motor flange and the drive unit. Use 2 screws
7
Figure 7-128. Bottom of Traction Motor
2. If the pinion needs to be installed: a. Clean the threads using thread primer (P/N 990-666). b. Install the key and gear.
Publication Number: 1043922B, Revised: 2 Sept 2015
7-65
