Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
Always watch for pinch points when using a press or pressing tools.
71826_094.tif
Figure 7-80.
Applying Locking Compound to screw
10. Spin the helical gear to make sure there is no end play or that the bearings are not too tight. 71826_097.tif
Figure 7-82.
Axle Assembly 1. Lubricate the oil seal. Place the seal over the axle shaft with the spring side toward the oil.
Axle Bearing Cone Installation
3. Apply a thin layer of gasket compound to the housing to seal the axle seal. See Figure 7-83.
71826_100.tif 71826_096.tif
Figure 7-81.
Axle Seal Installation
2. Place the axle bearing cone over the axle shaft. Press the bearing cone on the axle shaft until it is seated. See Figure 7-82.
Figure 7-83.
Apply Gasket Compound to Sealing Surface
4. Place the bevel gear into the housing. See Figure 7-84.
Publication Number: 1043922B, Revised: 2 Sept 2015
7-43
