Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
71826_080.tif
Figure 7-72.
Bevel Gear Bearing Cup Installation
71826_085.tif
Figure 7-74.
4. Place the drive axle bearing cup in the housing. Use a mallet or press to seat the axle bearing cup in the housing. See Figure 7-73.
Helical Bearing Cup Installation
Helical Gear/Spiral Pinion Gear Assembly NOTE: The pinion shaft and bevel gear are a matched set. Their alignment is critical. Do not replace them separately.
Bearing can become extremely hot. Use gloves to protect hands from burns. 1. Preheat the bearing cone with a bearing heater. See Figure 7-75.
71826_084.tif
Figure 7-73.
Axle Bearing Cup Installation
5. Turn the drive unit housing over. Install the helical bearing cup in the housing. Use a press or mallet to seat the bearing cup in the housing. See Figure 7-74.
71826_087.tif
Figure 7-75.
Preheat Bearing Cone
NOTE: Steps 2 thru 5 need to be completed before the bearing cools to provide a correct installation. 2. Install the heated bearing cone in the bearing cup in the housing.
