Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
71826_039.tif
Figure 7-58.
Puller Clamp on Bevel Gear
71826_051.tif
Figure 7-60.
2. Press the bearing from the bevel gear using a bearing press and an 8 in. tube. See Figure 7-59.
Puller Clamp on Spiral Gear
2. Press the bearing from the spiral gear using a bearing press. See Figure 7-61.
71826_040.tif
Figure 7-59.
Press Bearing from Bevel Gear
Spiral Gear Disassembly 1. Place a bearing puller clamp beneath the bearing cone on the spiral gear. See Figure 7-60.
Publication Number: 1043922B, Revised: 2 Sept 2015
7-37
