Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
71826_047.tif
Figure 7-50.
Lift Bearing from Housing
71826_055.tif
Figure 7-52.
Bearing Cup and Shim Removal NOTE: The bearing cups and cones are usually damaged during removal. They must be replaced as sets.
Helical Gear Bearing Cup Removal
3. Remove the axle shaft bearing cup from the housing using the punch and mallet. See Figure 7-53.
Bevel Gear Bearing Cup
1. Use the mallet and a long punch to drive the spiral gear bearing cup from the housing. Take care not to damage the shims. Save the shims for reference in reassembly. See Figure 7-51.
Axle Shaft Bearing Cup 71826_057.tif
Figure 7-53.
Axle Shaft and Bevel Gear Bearing Cup Removal
4. Use the mallet and a punch to drive the bevel gear bearing cup from the housing. Take care not to damage the shims. Save the shims for reference in reassembly. 71826_053.tif
Figure 7-51.
Spiral Gear Bearing Cup Removal
2. Use the mallet and a punch to drive the helical gear bearing cup from the housing. See Figure 7-52.
5. Visually inspect the housing bores and sealing surfaces for damage or wear.
Spur Gear Removal Check the spur gear for damage or wear. If the spur gear is damaged, use a drift punch and mallet to remove it from the housing. See Figure 7-54.
Publication Number: 1043922B, Revised: 2 Sept 2015
7-35
