Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
Due to normal or excessive wear, the edges of the radial rings could be very sharp. 2. Clean the grease from the radial ring channel in the housing. Inspect the channel for uneven wear. See Figure 7-41. If there is excessive wear, no further disassembly is necessary. The housing must be replaced. 71826_029.tif
Figure 7-43.
Turn Clamp Nut Off
3. Remove the axle from the housing using a large mallet. See Figure 7-44.
71826_026.tif
Figure 7-41.
Inspect Housing Channel
Axle Shaft and Bevel Gear Removal 1. Loosen the set screw locking the clamp nut using a 4 or 5 mm Allen socket and a breaker bar. See Figure 7-42. You may need to use an Allen wrench if access is limited.
71826_030.tif
Figure 7-44.
Remove Axle from Housing
4. The bevel gear can now be lifted from the housing. In cases where severe chipping is present, you may need a mallet to knock the bevel gear loose. See Figure 7-45.
71826_027.tif
Figure 7-42.
Loosen Clamp Nut Set Screw
2. Use a screwdriver in the clamp nut slot to turn the clamp nut off. See Figure 7-43.
71826_038.tif
Figure 7-45.
Publication Number: 1043922B, Revised: 2 Sept 2015
Lift Out Bevel Gear
7-33
