Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Drive and Brake
Drive Unit
Pivot Ring Disassembly 1. Remove the bearing filler plug screws using a 1/2 in. socket. See Figure 7-33.
4. After removing all the steel balls, remove the pivot ring by lifting it off, toward the drive end of the housing. See Figure 7-35.
71826_015.tif 71826_011.tif
Figure 7-33.
Bearing Filler Plug Screws Removal
2. Remove the bearing filler plug with grease fitting.
Figure 7-35.
Pivot Ring Removal
5. Use a screwdriver to remove the radial rings and thrust ring from the pivot ring. See Figure 7-36.
3. Remove the steel balls through the bearing filler plug hole. To work the steel balls forward, insert a putty knife between the pivot ring and the housing. See Figure 7-34. Use care to prevent damaging the radial rings. Move the pivot ring slightly from side to side while working the putty knife toward the bearing filler plug hole. NOTE: If the pivot ring does not spin or even turn, it is an indication of damaged radial rings and/or excessive wear to the channel in the housing. If this is the case, replace the entire drive unit. No further disassembly is necessary.
71826_018.tif
Figure 7-36.
Radial and Thrust Ring Removal
Due to normal or excessive wear, the edges of the radial rings could be very sharp. 6. Use a mallet and a punch to remove the spherical bearing and brass bushing from the pivot ring. See Figure 7-37.
1826_014.tif
Figure 7-34.
Remove Steel Ball Bearings
