Model 5200 High-Level Orderpicker
Section 7. Component Procedures
Steering and Controls
Proximity Sensor Adjustment
Proximity Sensor Adjustment 1. Turn the key switch OFF and disconnect the battery connector. 2. Loosen the two lock nuts securing the sensor to the bracket. See Figure 7-30.
Home Reference Proximity Sensor
7
Figure 7-30.
Home Reference Proximity Sensor
3. Adjust the vertical gap between the sensor and the sensor rail to 0.06 ± 0.04 in. (1.5 ±1 mm). Tighten the lock nuts. 4. Reconnect the battery connector and turn the key switch ON. 5. Center the drive wheel. The sensor should be installed horizontally just past the end of the sensor rail. When installed correctly, the amber LED on the proximity sensor is lit.
