Model 5200 High-Level Orderpicker Code 1,8
Code 1,8 Title
Lift potentiometer out of neutral
Reason
Voltage at start-up is greater than 1.7 or less than 0.6.
System Response
Travel shutdown
Alarm Sounds
No
Operator Display
¤ ¤¤¤¤¤¤¤¤
PC Contactor
Open
Speed Limit
0 mph
How to Clear
Turn the key switch OFF and ON.
Corrective Actions and Checks NOTE: Adding capacitor assembly P/N 1043322 between B- and the lift truck frame reduces noise in the system, which may cause intermittent codes. Connect black wire to TP4 and gray wire to one of the bolts that mounts the contactor assembly to the frame. Step
Action/ Meter Setting
1
DCV
(+) Lead JPCH9-6
NOTE: The Carriage Card and Steer/Tractor Manager S/W must be correctly matched. Installing a new carriage control card with the old software results in this code. The new card was cut into production on lift truck serial number 520-14-03473.
(–) Lead
Expected Results
Step Passed
Step Failed
JPCH9-4
For S/W below 2.5: Neutral = 0.6 to 1.7 volts
Run Learn. If Code is still displayed, replace the CM
Adjust or replace the potentiometer
For S/W 2.5 and up: Neutral = 1.1 to 1.4 volts
Publication Number: 1043922B, Revised: 2 Sept 2015
6-45
