Model 5200 High-Level Orderpicker Operator Display Fault Codes
Operator Display Fault Codes Fault Code messages are displayed in two locations; on the Operator Display (Battery Indicator), and in the tractor compartment on a two-digit display located on the Steer/Tractor Manager circuit card. See Figure 6-8. On the Operator Display, all five LEDs flash in series to identify the fault code. Each series (code) has two digits. If more than one code is present (“stacked codes”), there are rapid flashes between codes. See “Fault Codes” on page 6-3. On the two-digit display, the fault code is displayed in numerical form.
Fault Code Display
6
Figure 6-8:
Steer/Tractor Manager Card
There is no limit to the number of stacked codes, but only the highest priority codes are displayed. When these codes are resolved, the next highest codes are displayed until they are resolved.
Publication Number: 1043922B, Revised: 2 Sept 2015
6-41
