Renewing outer wheel housing liner
WARNING
Observe safety notes! Welding, parting using spark generating machines/tools or tin‐ ning in foam treated areas creates gases which are hazardous to health and environment. Therefore, refrain from using these processes. Safety notes ⇒ General Information; Body Repairs, General Body Repairs ; Safety notes •
Side panel already removed ⇒ page 332 .
1 - Wheel housing liner 2 - Reinforcing plate 3 - Bonded areas 4 - Moulded foam element
