Passat 2011 ➤ , Passat Variant 2011 ➤ Body Repairs - Edition 04.2011 RO: 53 55 55 60
12
Renewing side panel (Variant) - part section
WARNING
Observe safety notes! Welding, parting using spark generating machines/tools or tin‐ ning in foam treated areas creates gases which are hazardous to health and environment. Therefore, refrain from using these processes. Safety notes ⇒ General Information; Body Repairs, General Body Repairs ; Safety notes 1 - Side panel 2 - Moulded foam elements 3 - Parting cut for D-pillar 4 - Bonded area 5 - Parting cut to side member 6 - Parting cut for C-pillar
ht rig py Co t.
agen lksw Vo by
AG.
Prote cted by
c o p yri gh t . C op yi
Rep. gr.53 - Body - rear
do c um en
342
