Passat 2011 ➤ , Passat Variant 2011 ➤ Body Repairs - Edition 04.2011 RO: 53 30 55 52
9
Renewing inner D-pillar
WARNING
Observe safety notes! Safety notes ⇒ General Information; Body Repairs, General Body Repairs ; Safety notes •
Side panel already removed ⇒ page 342 .
•
Tail light mounting already removed ⇒ page 291 .
•
Cross panel already removed ⇒ page 273
1 - Sealing channel 2 - Inner D-pillar 3 - Rear longitudinal member 4 - Bonded area
