Passat 2011 ➤ , Passat Variant 2011 ➤ Body Repairs - Edition 04.2011 RO: 53 30 55 50
8
Renewing D-pillar reinforcement part section
Includes: sealing channel - part section WARNING
Observe safety notes! Welding, parting using spark generating machines/tools or tin‐ ning in foam treated areas creates gases which are hazardous to health and environment. Therefore, refrain from using these processes. Safety notes ⇒ General Information; Body Repairs, General Body Repairs ; Safety notes •
Side panel already removed ⇒ page 342 .
•
Tail light mounting already removed ⇒ page 291 .
1 - Moulded foam elements 2 - Cutting point 3 - D-pillar reinforcement
