– Weld roof side member to door apertures, RP spot weld seam (inverter).
5.4
Foam treating roof side member
5.4.1
Treating with foam
– Heat 2K structural foam cartridge in an approx. 60 °C water bath for 20 minutes.
166
Rep. gr.51 - Body - centre
AG.
Both weld symbols are shown in the figure.
agen lksw Vo by
Prote cted by c o p yri gh t. C op yi
Note
ht rig py Co t.
– Weld in B-pillar parting cut, MIG solder seam or SG continuous weld seam are permitted.
