CONTROLS/INSTRUMENTS/ACCESSORIES
Operator’s compartment fan (optional)
Articulated boom
Template Name: OM_1_col Template Date: 1994_04_29
Press the right-hand side of the button, the hom sounds. Press the left-hand side of the button, the boom closes.
Adjustable boom See “Adjusting the hydraulically locking adjustable boom” in the “Maintenance and Adjustments” Section.
Pilot system cancellation control switch (specific to certain countries)
CP95N001
TRIM THIS EDGE
Located on the rear right-hand side of the operator’s seat, the fan is controlled by a three-position switch (low, off, high) located on the bracket. To use the fan, the electric cable must be inserted into the cigarette lighter socket.
Articulated or adjustable boom control (if equipped)
Alt= to hide template information Alt+ to display template information
PH07604B
This control switch is located on the lefthand control arm and is used when driving on the road. When this control switch is operated, it is impossible to move the stabilizers, the dozer blade (if equipped) or the attachment and the indicator lamp on the instrument panel comes on.
CD99N012
Located on the end of the right-hand control lever, this push button enables the articulated or adjustable boom to be manoeuvred (whichever is equipped).
