ELECTRICAL SYSTEM
BATTERIES Check electrolyte level ............................................................. at least once a year
Access to batteries
Checking electrolyte level
PH07326
PG03613
Remove the side hood, then remove the protectors. See “Replacing a battery".
Remove the plugs and check the electrolyte level in each battery cell. The level should be between 10 and 15 mm above the separators.
TRIM THIS EDGE
Add distilled water, if necessary. Make sure the battery terminals are clean and coated with grease and that the cables are tightly connected.
317
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Before servicing components of the electrical system, always place the battery master switch key in the disconnected position (electricity cut off in system).
Alt= to hide template information Alt+ to display template information
Service specifications
