MAINTENANCE/ADJUSTMENTS
ENGINE ALTERNATOR BELT AND FAN Visual inspection ........................................................ Every 10 hours or every day Check drive system..................................................................... Every 1000 hours Check belt tension....................................................................... Every 1000 hours
Tools required
STEP 3
- One 13 mm wrench for hexagonal head screws - One 15 mm wrench for hexagonal head screws
PE06831
Check that the fan is in proper working order (the hub should turn freely without excessive play). STEP 4 Check the condition of the belt. Replace it if it is worn or damaged and install the belt.
CD98E013
Remove the fan guard. STEP 2
TRIM THIS EDGE
STEP 1
Alt= to hide template information Alt+ to display template information
Service specifications
PE06828
Loosen the tension roller and remove the belt. Check that the tension roller and pulley are in proper working order (the pulley should move freely).
PDE0090
Measure the slack along the longest straight section of the belt. Maximum slack: 9.5 to 13 mm. Install the fan guard.
269
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
STEP 5
