LUBRICATION/FILTERS/FLUIDS
Coolant level Template Name: OM_1_col Template Date: 1994_04_29
The level of coolant solution should be checked when the engine is cold.
!
WARNING: Do not remove the reservoir cap while the engine is hot. The cooling system will still be under pressure and you could be scalded.
STEP 2
CD98E013
TRIM THIS EDGE
Check the level on flat, level ground, before using the machine (while the engine is still cold). The level in the coolant reservoir should be in the middle of the sight glass. If not, see “Filling”.
Draining
CD99N001
Move the heating control to the left (open). STEP 3
Tools required
Alt= to hide template information Alt+ to display template information
- One 17 mm wrench for hexagonal head screws - One flat-headed screwdriver STEP 1
PG03004
Remove the screws and the lower tray under the operator’s compartment.
CD98E013
Remove the coolant reservoir cap.
226
