LUBRICATION/FILTERS/FLUIDS
ENGINE Service specifications Template Name: OM_1_col Template Date: 1994_04_29
Oil level check .............................................................Every 10 hours or every day Oil change ..................................................................................... Every 250 hours Oil filter replacement ..................................................................... Every 250 hours Type of oil......................................................................See “Fluids and lubricants” Oil capacity: - without filter replacement ................................................. 14.3 liters - with filter replacement ...................................................... 15.3 liters
Engine oil level STEP 1
STEP 3
Park the machine on flat, level ground. Stop the engine and remove the starter switch key. STEP 2
TRIM THIS EDGE
CD9E015
Alt= to hide template information Alt+ to display template information
CD98E015
Fifteen minutes after stopping the engine, remove the dipstick, wipe it with a clean cloth and push it back into the guide tube as far as the stop and then pull it out again and check the oil level. PH08208
If the oil level is below the ADD (minimum) mark, remove the filler cap and add oil up to the FULL (maximum) mark on the dipstick and install the cap. NOTE: The oil level should not exceed the FULL (max) mark on the dipstick.
222
