JOB SITE AND ROAD OPERATION STEP 6
STEP 7
Template Name: OM_1_col Template Date: 1994_04_29
Lock the boom and dipper positions by means of the boom and dipper locking valves. See "Boom locking valve" and "Dipper locking valve" in the "Controls/ Instruments/Accessories" Section.
TRIM THIS EDGE
PDH0187
Hook the teeth of both shells onto the bar (1) by operating simultaneously the controls for boom, boom articulation, dipper and clamshell closing. The attachment will be in the road transport maximum overall dimension position when the boom and boom articulation cylinders are extended to the maximum. Then raise the dozer blade (2AL version)
Alt= to hide template information Alt+ to display template information
1
173
